Cheese filling machine( MIC-ZF6 6heads piston filling and capping machine)
  • parameter
  • Features
  • configuration

Filling head

6 heads

Filling volume range

100ml-5Laccording to customer different bottle volume customize the control filling volume cylinder

Production speed

1300-1500 Bph basis on100ml bottle

Voltage

220v/380v

Power

2.8kw

Suitable bottle’s diameter

Ф40mm-Ф250mm

Filling error

≤±1

Work pressure

0.55Mpa-0.65Mpa

Size

1840mm*1400mm*2500mm

Weight

600kg

Air consumption

0.9m^3/min

This machine is suitable for filling water and cream products, especially for high viscosity materials (such as washing liquid, suspending agent, colloidal suspension agent,  oil , cream ,etc.) the effect is obvious. PLC programming control, with a touch screen and man-machine interface system; automatic bottle feeding, automatic filling, automatic bottle; the servo motor drive, double screw drive, the control piston rod movement to ensure the filling stability, filling accuracy higher. It can be with the capping machine, labeling machine supporting the formation of water production line.  It integrates light, machine, electricity and gas into one body. Is an easy to operate filling machine. With stable and reliable operation, high production efficiency, strong adaptability.

Touch screen

Canada xinjie color

PLC

Schneider

Solenoid valve

Taiwan Airtac

Optoelectronic system

OPTEX

Micro differential pressure switch

Netherlands

Servo motor

Taiwan TECO

Air source treatment

Taiwan Airtac

Button and low voltage electric appliance

Schneider

Ball screw

Taiwan

Reducer

Taiwan VGM

Switching power supply

Taiwan meanwell

Material

Contact with the material parts of the 316 materials, and the rest of the 304 stainless steel
